[Aeryx]
Fixed-Wing UAS


[Aeryx] is a fixed-wing drone for the modern warfighter. No other platform delivers the same level of durability, waterproofIng and modularity. [Aeryx] flies in wet weather conditions without any problems through its fully waterproof design and can fly with or without GPS for long durations.
Â
[Aeryx] is a 12.5kg MTOW, up to 5kg payload capacity, up to 4hrs flight time, man-portable and ruggedised UAS. The system allows for covert operations to deliver effects. High-rate manufacture as been designed into the platform from an early stage. All UAX platforms incorporate learnings from global conflicts around the world ensuring the mission is never compromised and effect can always be delivered. With modularity in-mind, avionics are swapped in deployed locations without specialist training to ensure operational readiness.
[Aeryx]
-
[12.5kg] Maximum Take-Off Weight (MTOW)
-
[5kg] Payload Capacity
-
[23m/s] Cruise Speed
-
[15/ms] Wind Resistance
-
[>200km] Mission Range
-
[Up to 4hrs] Mission Endurance
-
[Up to 140km] Datalink Range
-
[+50°C to -10°C] Operating Temperature
-
[-40°C] Modification Kit Available​
-
Hot/High Modification Kit Available
-
​
-
Electric Propulsion
-
Man-Portable
-
Fully Waterproof
-
GNSS-Denied Navigation System
-
Customisable Payload bay via Interface Control Document
-
Redundant and Optionally Independent Command and Control Link
-
NDAA Compliant
​
Specification

Surveillance
-
Basic ISR
-
Advanced ISR
-
Passive AI-ISR
-
Signal Intelligence
-
Jamming Detection
Mission Coverage
Support
-
Blood Delivery
-
Equipment Resupply
-
Radio Rebroadcasting
-
Emergency Power Delivery
-
Customised Payloads with 5kg and 5 litre capacity
